2 Ton Forklift Purchase
FEATURES
Energy Saving/New
A Radical Innovation To Establish a new industry model How can we design the forklift so as to satisfy the needs of managers,drivers and piled goods!
Socma naswers this question by its latest series forklift after a wholly devoted research. To cater for clients' new needs for forklift's function,Socma has further improved its unique hydraulic technology.
Socma has not only maintained its exclusive durability and reliability ,but also armed their product with new fuction,aiming to promote its operational capacity ,security and efficiency.We can see this new achievement from its uniquely improved uploading system,the design of cab,operating lever and the car body. keeping improving ,as Socma forklift's design principle,has been embedded into every single detail .
By all these devotion,we has produced the world class production which enables every user to operate in a comfortable way.
Socma small and big forklift advantage
High Efficiency
Energy Saving
New
A Radical Innovation To Establish a new industry model How can we design the forklift so as to satisfy the needs of managers,drivers and piled goods!
Socma naswers this question by its latest series forklift after a wholly devoted research. To cater for clients' new needs for forklift's function,Socma has further improved its unique hydraulic technology.
Socma has not only maintained its exclusive durability and reliability ,but also armed their product with new fuction,aiming to promote its operational capacity ,security and efficiency.We can see this new achievement from its uniquely improved uploading system,the design of cab,operating lever and the car body. keeping improving ,as Socma forklift's design principle,has been embedded into every single detail .
By all these devotion,we has produced the world class production which enables every user to operate in a comfortable way.
1.Removable side cover is much more conducive to inspection and simple repairs.
2.Fuses,relays and other electric elements are integrated into a control box,which makes the maintenance and inspection work more convenient.
3.On the basis of increasing the radiator,we use the aluminum for heat sink which has emhanced significantly the cooling effect. 4.Plus large double muffler has superior noise reduction effect.
5.The new suspension system,adjustable seat,allowing the driver to feel more comfortable and reducing fatigue during long time operations.
6.Step area is about 1.5 times of similar forklift.while the step height is lower ,more conducive to the driver on forklift
7.The car breast skin with buttons removes a hidden danger of security due to hand slip of operator.
8.The broad flat dues to sunken till cylinder under the floor,which makes a larger space for the driver's steering
9.Embedded LCD isntrument,with neutral display ,if not placed in the neutral position, the engine can not be started.
10.Double protection type brake lever to prevent misuse case.
11.Introducing advanced technology from Germany,the unique single chain has greatly enhanced the front view 12.With an excellent head protection design,this plastic ceiling make it possible to work safety even in rainy day.
PIC;JOHN CHEN
WA;0086 18106938692
EMAIL;john@socmachinery.com
Related Products Video
PARAMETER
| Model | UNIT | FD20T | ||||
| Specifications | Power Unit | Diesel | ||||
| Operator Type | Driver/seat | |||||
| Transimission Bo× Type | Electronic hydraulic transmisson | |||||
| Rated Capacity | kg | 2000 | ||||
| Load Center | mm | 500 | ||||
| Ma×.Lifting Height | mm | 3000 | ||||
| Tire Type | Pneumatic Tyre | |||||
| Tire Number | Front | 2 | ||||
| Rear | 2 | |||||
| Tire Size | Front | 7.00-12-12PR | ||||
| Rear | 6.0-9-10PR | |||||
| Performance | Lifting Speed | Loaded | mm/s | 500 | ||
| Unloaded | 550 | |||||
| Lowering Speed | Loaded | mm/s | 480 | |||
| Unloaded | 450 | |||||
| Travelling Speed | Loaded | km/h | 17 | |||
| Unloaded | 19 | |||||
| Ma×.Gradeability (Loaded) | % | 21 | ||||
| Ma×.Drawbar Pull (Loaded) | kn | 18 | ||||
| Mast Tilting Angle (Fwd/Bwd) | deg | 6/12 | ||||
| Free Lifting Height | mm | 150 | ||||
| Turning Radius | mm | 2170 | ||||
| Dimensions | Overall Length (without fork) | mm | 2605 | |||
| Overall Width | mm | 1150 | ||||
| Overhead Guard Height | mm | 2090 | ||||
| Fork Size (L×W×T) | mm | 1220×122×40 | ||||
| Mast Height (Fork lowered) | mm | 2090 | ||||
| Battery (Voltage/Capacity) | V/Ah | 12/90 | ||||
| Truck Weight | kg | 3380 | ||||
| Fuel Tank Capacity | L | 70 | ||||
| Engine | Brand | ×INCHAI | MITSUBISH | ISUZU | ||
| Model | C490 | S4S | C240 | |||
| Rated Power | kw/rpm | 40/2650 | 35.3/2250 | 35.4/2500 | ||
| Rated torque | n-m/rpm | 160/1600-2000 | 169/1700 | 137.7/1800 | ||
| Number Of Cylinder | 4 | 4 | 4 | |||
| Displacement | 2.67 | 2.49 | 2.37 | |||
Related Products Photos






Socma Forklift related news and information
Engine oil is indispensable for automobiles and forklifts. In many cases, the quality of engine oil will also affect the use of forklifts.
Everyone knows why the oil of forklifts or cars needs to be changed regularly? For a forklift like a forklift, the main reason for adding oil is to form an oil film on the frictional parts of the engine through the sleeve to make the dry friction between the metals into liquid friction between the oil layers, reducing the frictional resistance and reducing the machine. At the same time, the oil also plays a role in cooling, cleaning, sealing, rust prevention and eliminating impact load. However, the quality of engine oil on the market is uneven. Many people use inferior engine oil for the sake of cheapness. Everyone should pay attention to the fact that if you use inferior engine oil, it will not only fail to maintain the car, but it will also have many negative effects. Now I will talk to you about the hazards of low-quality engine oil.
1. The counterfeit and inferior engine oil has poor acid resistance and neutralization ability, so that the acid formed by the reaction of the water generated in the engine working process and the sulfide generated after the combustion of the fuel cannot be neutralized, which causes the engine to be corroded by acid.
2. Poor cleaning and dispersion performance. Counterfeit and inferior engine oil not only can not clean the dust and coke formed after combustion in the air when the engine is working, but also the colloid generated by its own oxidative deterioration combined with other impurities to produce more Carbon deposits caused by poor lubrication, increased wear and tear, increased fuel consumption, reduced power, and even blocked oil passages, causing accidents such as cylinder pulling and bushing.
For your own forklift, you should use better oil, which will also avoid many problems and protect your forklift.
