SOCMA 13.5t Electric Forklift HNF135-EL
2.Kessler drive axle & Danfoss hydraulic system
3.141kWh Lithium battery, 7-9h operation
4.ROPS/FOPS cab with climate control
5.Energy recovery & PMSM motor
1. SOCMA HNF135-EL Introduction
This 13.5-ton lithium-ion electric forklift delivers high-performance heavy-duty material handling with eco-friendly efficiency. Equipped with a 141kWh large-capacity battery, it offers 7-9 hours of endurance and supports 120kW dual-gun fast charging to minimize downtime. Premium components like Germany's Kessler drive axle and Denmark's Danfoss pumps ensure durability and reliability.
The permanent magnet synchronous motor, combined with energy recovery (potential + braking energy), reduces consumption to just 12-16kWh/h. Its 3500mm two-stage wide-view mast and 1900mm forks handle bulky loads effortlessly, while the quick-change shelf enhances versatility.
The ROPS/FOPS-certified closed cabin features AC & heating for operator comfort. The battery heater maintains performance in cold environments, and pneumatic tires adapt to rough terrain. Ideal for ports, steel mills, and heavy manufacturing, it's a zero-emission solution for demanding logistics.
2. SOCMA HNF135-EL Specification
| Performance | Parameter | |
| Basic Parameter |
Model |
HNF135-EL |
|
Power unit |
Lithium battery pure electricity |
|
|
Rated capacity |
13,500kg |
|
|
Load center |
600mm |
|
|
Turning radius (outside) |
5500mm |
|
| Parameter |
Travelling speed (load/unload) |
16/20 km/h |
|
Max. Lifting height (load/unload) |
220/270 mm/s |
|
|
Max. Lowering speed (load/unload) |
340/320 mm/s |
|
|
Traction |
60kN |
|
|
Gradeability (load/unload) |
20%(15%/20%) |
|
| Battery |
Battery type |
Lithium Iron Phosphate |
|
Battery rated storage capacity |
141kwh |
|
|
Rated capacity of battery |
228AH |
|
|
Rated voltage |
618V |
|
| Driving system |
Motor type |
Permanent magnet synchronous motor |
|
Motor rated |
90kW |
|
|
Transmission |
Motor direct drive |
|
| Hydraulic system |
Motor type |
Permanent magnet synchronous motor |
|
Motor ratedpower |
74kw |
|
|
Pressure |
20 MPa |
|
