China Manufacture SOCMA Brand HNF-160S 16t Capacity Forklift
SOCMA forklift small 16ton @load center 600mm with OEM service and different attachments
Model:HNF-160S
1. Hydraulic transmission
2. Engine:Cummins engine QSB4.5-C130
3. Weight: 19ton
4. Load Capacity:16ton
5. Load center:600mm
6. Wheel Base:3300mm
7. Fork Size: 1200*180*90mm
8. Fork with positioner &side shifter
9. Duplex mast lifting height:3000mm
10. Max lifting height:3500mm
11. Air Cab
12. Side shift & Positioner
ITEM | Model:HNF-160S | |
Features | Rated Load | 16000kg |
Load center | 600mm | |
Wheelbase | 3000mm | |
Weight | Weight | 19000kg |
Chassis | Tyre Specs.:Front | 12.00-20-18PR |
Tyre Specs.:Rear | 11.00-20-18PR | |
Tyres Qty,front/rear(X-drive wheels) | 4\2 | |
Wheel tread:Front | 1677mm | |
Wheel tread:Rear | 2013mm | |
Dimension | Mast/carriage tilt angle(front/rear) | 6\12 ° |
Mast height(fork lowering) | 3100mm | |
Mast lifting height | 3000mm | |
Max.lifting height | 4600mm | |
Height to head guard(height to cab) | 3000mm | |
Overall height(with forks) | 6355mm | |
Fork front vertical surface to the rear end of the vehicle | 5155mm | |
Overall width | 2400mm | |
Fork dimension | 1200X180X90mm | |
Fork carriage width | 2200mm | |
Mast min ground clearance(with load) | 225mm | |
Wheelbase center min ground clearance(with load) | 350mm | |
Min.Turning radius | 4450mm | |
Travel speed(with load/without load) | 23/26mm | |
Performance | Max.lifting speed(with load/without load) | 220/270 mm/s |
Max.Lowering speed(with load/without load) | 450/300 mm/s | |
Traction | 90KN | |
Gradeablity(with load/without load) | 20/22 % | |
Driving brake | Hydraulic clamp disc | |
Engine | Engine brand/model | Cummins |
QSB4.5-C130 | ||
Displacement | 4.5 L | |
Rated Power | 97 KW | |
Rated Turning Speed | 2200 rpm | |
Cylinder No. | 4 | |
Others | Transmission gears(Front/rear) | 2\2 |
Attachments working pressure | 16 MPa | |
Attachments using oil amount | 40 L/min |
