25t Lithium Battery Electric Heavy Duty Forklift On Sale
2.used Hangchi, Sanchi planet type hydraulic power shift transmission, big traction in combined operating condition.
3.adopt double turbine hydraulic torque converter, stepless speed change, single level control for the speed changing.
4.variable speed control valve matched with neutral starter, the machine start more secure.
5.front axle adopt heavy duty type driving axle, enlarge the size of axle housing, hub and bearing, spiral bevel gear and wheel planetary wheel deceleration increasing twist,steel structure bridge shell support, increase the load capacity and service life.
Specifications of 25t lithium battery electric heavy duty forklift for sale:
Configuration | Model | Unit | HNF250-EL | |
Vehicle configuration | HNF250-EL | |||
Performance | Rated load | 25000 | ||
Load center | 1250 | |||
Mast tilt angle (front/rear) | º | 6/12 | ||
Overall dimensions | Length | mm | 9190 | |
Width | mm | 3050 | ||
Height | mm | 3860 | ||
Mast lifting height | mm | 3500 | ||
Fork size (L*W*H) | mm | 2440X300X110 | ||
Min. turning radius | mm | 6700 | ||
Max. travel speed (with load) | Km/h | 25 | ||
Lifting speed (with load) | mm/s | 260 | ||
Gradeability (with load) | % | 20 | ||
Weight | Kg | 35000 | ||
Tyre | Front | 4X14.00-24/28PR | ||
Rear | 2X14.00-24/28PR | |||
Wheel tread | Front | mm | 2200 | |
Rear | mm | 2390 | ||
Wheelbase | mm | 4400 | ||
Min. ground clearance | mm | 300 | ||
Motor | Moto type | perermanent synchronous motor | ||
Motor rated power | KW | 90 | ||
Transmission type | Mechanical transmission, automatic shifting | |||
Fujian Southchina Heavy Machinery Manufacture Co., Ltd. was found in 2010, who is dedicating the research & development of material handling equipment and construction products：
1.material handling equipment incuding heavy duty forklift, rough terrain forklift, telescopic forklift
2.construction machinery inluding wheel excavator, wheel loader
3.furnace-tending vehicle&furnace-charging vehicle, which is customized for using in the metal smelting industry.
