SOCMA Official 45 Tons Heavy Duty Forklift used in Port with container spreader
Lifting height (standard) mm 9200
Mast tilting angle (α/β) Grad 2/10
Stacking layers Layer 3X9.6”
Front overhang (L4) mm 980
Wheel base (L3) mm 5500
Mast height (lowered/up) mm 6780/12860
Spreader width (Min/Max.) mm 6050/12175
Spreader side shifting mm ±220
Spreader turn left/turn right Deg ±6
Turning radius (Inner) mm <750
Turning radius (Outer) mm 7900
Turning radius (spreader draw back/extend) mm 6900/9670
Operating weight kg 70000
Travel speed (Loaded/unload) km/h 22/24
Max. Gradeability Grad 25
Overall length mm 10700
Overall width mm 6050
Overall height mm 6780
Chassis Width mm 4220
Wheel tread (T1/T2) mm 3030/2895
Min ground clearance mm 435 Engine Cummins QSM11
kW 250
Transmssion Dana Transmission
Front tyre 18.00-25-40PR
Rear tyre 18.00-25-40PR
SOCMA takes clients' demands as our guideline.
This is heavy duty forklift is the variety of our tradictional one. But the usage area is too narrow to put the reach stack. So the client contacts us to give him an available plan to deal with that issue.
And then, our researcher and development technicians have work for hundred hours to draw up such a plan.
The customization also could be created by you.
Moreover, we are the manufacturer with our own factory, OEM/ODM is our special unique service.
SOCMA power lifts your business.
Our manufacturing capacity will help you to finish saveral kinds of machinery. As forklift, excavator, loader.
Hot Tags: socma official 45 Tons Heavy Duty Forklift used in Port with container spreader, China, manufacturers, factory, customized
