Fujian South China Heavy Industry Telehandler Tonnage: 2.5 tons covering 7 tons
Lifting height: 7 meters to cover 17 meters
Telehandler Manufacturer: South China Heavy Industry
Place of Origin: Quanzhou City, Fujian Province
The forks of the telescopic forklift truck can cross obstacles, pass through orifices, etc. for forklift operations, and can perform stacking and de-stacking operations of multiple rows of goods under complex working conditions. SOCMA Telescopic forklifts same as JCB, CAT telehandler, which has good front visibility and low requirements for aisle clearance and is usually also classified as off-road forklifts.
3.5-ton telescopic forklift custom lift height 8.8 meters 3.5-ton telescopic forklift
Fujian South China Heavy Machinery Telehandler Tonnage: 3.5 tons to 7 tons
Lifting height: 8.8 meters
Telehandler Manufacturer: SOCMA
Place of Origin: Quanzhou City, Fujian Province, China
| Item | Unit | HNT35-4 | ||
| Main Spec. | Rated lifting capacity | kg | 3500 | |
| Load center | mm | 500 | ||
| Lifting capacity in max. outreach | kg | 1550 | ||
| Max. working height for basic boom | mm | 4850 | ||
| Max. working height for whole arm | mm | 8800 | ||
| Max. outreach | mm | 3350 | ||
| Min. outreach | mm | 930 | ||
| Min. ground clearance | mm | 400 | ||
| Min. turning radius | mm | 6200 | ||
| Amplitude elevation angle | Max. elevation of the boom | ° | 60 | |
| Min. elevation of the boom | ° | -11 | ||
| Operating weight | kg | 9000 | ||
| Overall size | Length with fork | mm | 5730 | |
| Width | mm | 2390 | ||
| Height | mm | 2485 | ||
| Wheel track (front/rear) | mm | 1870 | ||
| Wheel base | mm | 2700 | ||
| Transmission system | Max. traveling speed without load | km/h | 30 | |
| Max. gradeability | % | ≥30% | ||
| Tyres | Front (2) | - | 16/70-24 | |
| Rear (2) | - | 10.00-20-16 | ||
| Engine | DF Cummins | Model | 4BTA3.9-C80II | |
| Rated power | kW/rpm | 60/2000 | ||
