12 Ton Diesel Heavy Forklift Material Handling Machine
12 tons diesel forklift
Comminus engine
900 mm load center
Full-hydraulic steering
Full cab with AC
Comminus engine
900 mm load center
Full-hydraulic steering
Full cab with AC
Send Inquiry
Product Introduction
Heavy Duty 12 Ton Diesel Forklift
| Configuration | Model | Unit | HNF-120 | |
| Performance | Rated load | kg | 12000 | |
| Load center | mm | 900 | ||
| Mast tilt angle (front/rear) | ° | 6/12 | ||
| Overall dimensions | Length with fork | mm | 9590 | |
| Width | mm | 3800 | ||
| Height | mm | 4750 | ||
| Mast lifting height | mm | 8100 | ||
| Fork size (L*W*H) | mm | 2440X320X110 | ||
| Min. turning radius | mm | 7620 | ||
| Max. travel speed (with load) | Km/h | 24 | ||
| Lifting speed (with load) | mm/s | 260 | ||
| Gradeability (with load) | % | 20 | ||
| Weight | Kg | 45000 | ||
| Tyre | Front | 4X16.00-25/32PR | ||
| Rear | 2X16.00-25/32PR | |||
| Wheel tread | Front | mm | 2800 | |
| Rear | mm | 2450 | ||
| Wheelbase | mm | 4800 | ||
| Min. ground clearance | mm | 410 | ||
| Engine | Model | CUNNINS QSC8.3-C260 | ||
| Rated power/rotate speed | KW/r.pm | 194/2200 | ||
| No. of cylinder | 6 | |||
Q: Could you produce prodducts in our brand?
A: Yes, OEM/ODM is available. We do this ever before.
Q: Which kind of engine do you use？
A: Cummins, Weichai, Yuchai, Every engine depends on you.
Q: Could you accept O/A?
A: Yes, but it is just for some of our old client with good credit.
Q: How about driving system?
A: Different options for you.
Q: How about Fork?
A: Standard or customized
Q: How about Cab?
A: Good vision, with Air Condition
