SOCMA 32t Forklifts For Containers

SOCMA 32t Forklifts For Containers

SOCMA 32t forklifts vs kalmar 30t forklifts,tcm 32t forklifts,toyota 32t forklifts,Konecranes 32t forklifts,Caterpillar 32t forklifts,CAT 32t forklifts,Sany 32t forklifts, 32t forklifts,XGMA 32t forklifts,dalian 32t forklifts,
Send Inquiry
Product Introduction

SOCMA supply safe 32 ton forklift, environmentally friendly 32 ton forklift, durable 32 ton forklift, efficient 32 ton forklift, clean 32 ton forklift, long-term 32t forklift, stable and reliable 32 ton heavy duty forklift, forklift truck,

This 32t lifting truck load center:1250mm,32t forklift's total weight is 44000kg,with Cummins engine or weichai engine ,32t heavy duty forklift truck,32t heavy duty forklifts,32t forklifts,32t lift truck,32t lifting forklift for Large tonnage material handling,Highly professional,High cost performance forklift truck, high return on investment, abandoning the forklift truck's working pump is easy to heat, the whole vehicle is easy to roll over, the support shaft is broken due to the serious insufficient bridge load, and its own weight and load are doubled and the lower caliper disc brake exists. Big safety hazard! South China Heavy Industries only manufactures products that are responsible to users. The vertical lifting height of the load is three meters or more. It is suitable for mining areas, stone enterprises, terminal yard operations, lifting, loading and unloading, leasing industry, steel industry, etc. The warranty is two years, and it is a strong confidence in product quality! Welcome to call to the factory for small talk. Agents are welcome.

HNF-320


Technical parameter:

Configuration

Model

Unit

CPCD320

Vehicle configuration

HNF-320

Performance

Rated load


32000

Load center


1250

Mast tilt angle (front/rear)

º

3/4

Overall dimensions

Length

mm

9590

Width

mm

3800

Height

mm

5520

Max. lifting height

mm

6300

Height of mast extend

mm

8670

Fork size (L*W*H)

mm

2440X320X110

Min. turning radius

mm

7260

Max. travel speed (with load)

Km/h

25

Lifting speed (with load)

mm/s

260

Gradeability (with load)

%

20

Weight

Kg

44000

Tyre

Front


4X16.00-25-32PR

Rear


2X16.00-25-32PR

Wheel tread

Front

mm

2800

Rear

mm

2450

Wheelbase

mm

4800

Min. ground clearance

mm

400

Weichai Engine

Model


WD10G240E21

Rated power/rotate speed

KW/r.pm

175/2200

Cylinder No.


6

DF Cummins Engine(optional)

Model


QSC8.3-C260

Rated power/rotate speed

KW/r.pm

194/2200

Cylinder No.


6
