7 Ton Forklift Engine Chaochai big joe lift handling systems Work For Marble Stone Factory Lift Height 5 Meter Mast 3 Stage
High Efficiency
Energy Saving
New
A Radical Innovation To Establish a new industry model How can we design the forklift so as to satisfy the needs of managers,drivers and piled goods!

PIC;JOHN CHEN
WA;0086 18106938692
EMAIL;john@socmachinery.com
Parameter:
| Model | UNIT | FD70T | ||||
| Specifications | Power Unit | Diesel | ||||
| Operator Type | Driver/seat | |||||
| Transimission Bo× Type | Electronic hydraulic transmisson | |||||
| Rated Capacity | kg | 7000 | ||||
| Load Center | mm | 600 | ||||
| Ma×.Lifting Height | mm | 3000 | ||||
| Tire Type | Pneumatic Tyre | |||||
| Tire Number | Front | 4 | ||||
| Rear | 2 | |||||
| Tire Size | Front | 8.25×15-14PR | ||||
| Rear | 8.25×15-14PR | |||||
| Performance× | Lifting Speed | Loaded | mm/s | 450 | ||
| Unloaded | 500 | |||||
| Lowering Speed | Loaded | mm/s | 500 | |||
| Unloaded | 450 | |||||
| Travelling Speed | Loaded | km/h | 25 | |||
| Unloaded | 30 | |||||
| Ma×.Gradeability (Loaded) | % | 27 | ||||
| Ma×.Drawbar Pull (Loaded) | kg | 5400 | ||||
| Mast Tilting Angle (Fwd/Bwd) | deg | 6/12 | ||||
| Free Lifting Height | mm | 155 | ||||
| Turning Radius | mm | 3370 | ||||
| Dimensions | Overall Length (with fork) | mm | 4870 | |||
| Overall Width | mm | 2000 | ||||
| Overhead Guard Height | mm | 2480 | ||||
| Fork Size (L×W×T) | mm | 1220×150×65 | ||||
| Mast Height (Fork lowered) | mm | 2500 | ||||
| Battery (Voltage/Capacity) | V/Ah | 2×12/90 | ||||
| Truck Weight | kg | 9200 | ||||
| Fuel Tank Capacity | L | 135 | ||||
| Engine | Brand | ISUZU | MITSUBISH | CHAOCHAI | ||
| Model | 6BG1 | S6S-T | 6102 | |||
| Rated Power | kw/rpm | 82.3/2000 | 67.6/2300 | 80.8/250 | ||
| Rated torque | n-m/rpm | 418/1500 | 293/1700 | 354/1650 | ||
| Number Of Cylinder | 6 | 6 | 6 | |||
| Displacement | 6.49 | 4.99 | 5.78 | |||

Socma small and big forklift related information and new share
In the first half of 2018, the cumulative sales of motorized industrial vehicles reached 307,600 units, a year-on-year increase of 26.6%; cumulative exports were 79,600 units, a year-on-year increase of 35%.
Since January 2017, the sales of motorized industrial vehicles have continued to grow. Only in February this year was the decline due to the Spring Festival factor, and the remaining months achieved year-on-year growth; overseas markets have also performed strongly. Since January 2017, only Last May, export sales fell year-on-year.
In terms of types, internal combustion counterbalanced forklifts sold the most, with cumulative sales of 175,400 units in the first half of the year, accounting for 57% of total sales; followed by electric walking storage forklifts, with cumulative sales of approximately 96,600 units, accounting for 31.4% of total sales. The largest exporter was electric walking storage forklifts. In the first half of the year, a total of 42,800 units were exported, accounting for 53.8% of total exports; the second was internal combustion counterbalanced forklifts, which exported 29,400 units, accounting for 37% of total exports.
In the first half of the year, the export sales of motorized industrial vehicles accounted for 25.9% of the total sales. Among them, 44% of the electric walking storage forklifts were sold overseas, while the internal combustion counterbalanced forklifts accounted for only 16.8%.
