SOCMA 3t Diesel Wheel Loader 930 Grab Loader

SOCMA 3t Diesel Wheel Loader 930 Grab Loader

Hydaulic System

1. With SOCMA high pressure hydraulic system, and the Max bucket breakout force 102kN.

2. Large-diameter hydraulic pipe lines reduce energy consumption during hydraulic power transmission and reduce operating costs.

3. International level high-pressure pipeline equipment to reduce manufacturing defects to as low as possible like zero.

4. Advanced steel pipe welding technology ensures smooth weld seam no slag pollution and low flow resistance inside of pipes.

Electric System

1. Different sensors,combined with the instrument could timely grasp wheel loader working information, which makes the operation is more safe and efficient.

2. The wire harness is manufactured by world-class processing equipment and components, It is sealed well and corrosion-resistant for stable power supply.

3. Three sets of working headlights guarantee high brightness strong penetrating power, wide illumination range, and even high efficiency at night.

4. Advanced cold starting battery keeps long time energy storage and ensure stable power supply in low-temperature.

ATTACHMENT

1. Forged hydraulic cylinder head not easy to break, the piston rod is quenched by medium frequency with higher hardness strength and longer life.

2. The pin shaft uses 40Cr material and the tensile strenath is increased by 35%, it is matched with the O-ring dust-proofstructure to prevent the sediment from entering the pin hole The oil hole cylinder sleeve ensures that the pin shaft is fully lubricated.

3. The bucket,equipped with wear-resistant plate, is made of special steel plate. The bucket teeth are made ofwear-resistant alloy steel material+forging excavator bucket teeth technology. The wear resistance is 1.5~2 times higher than before

4. Unique SOCMA design of bucket shape make the transportation position angle up to48° Each bucket actual loading is more than before and the hopper does not spill during the walking Shovel cutting operations are more comfortable greatly increasing the full bucket rate and ensuring high outputratios for customers.

5. The electronic levelina device and the lifting cylinder limit system is useful to improve the control accuracy and improve the work efficiency.

TRANSMISSION SYSTEM

1. The hydraulic torque converter with the TEAM technology can achieve a hydraulic conversion rate more than 83% With the precision planetary power shift transmission,the gear shift is fast ensuring high-efficiencyoperation.

2. The new drive shaft adopts double universal joint intermediate support making toraue transmission more stable. The 7C flange effectively prevents the bolt from being damaged so that the connection is reliable.

3. The SOCMA 30 Wet axle with 100% intellectual property is an important step of the drive axle technology. It has been widely praised by customers both at home and abroad since its beginning.

4. The wheel oil seal is a new labyrinth oil seal model and a newventing cap structure model which has better sealing and anti-sand effect and is effective in extreme conditions.
