As electrification technology continues to advance, so does the range of machine types to which it’s applied. Electrically-powered wheel loaders are among some of the more recent machine introductions.
The lack of emissions will be an increasingly more important aspect as more cities begin implementing stricter emissions regulations and designating Low Emission Zones.
In addition, the noise levels of electrically-powered wheel loaders and other equipment is greatly reduced, enabling their use in residential areas or near livestock, further increasing the applications in which they can be used.
| Performance | Parameter | ||
| Basic Technical Parameter | Bucket Capacity Range (m³) | 3 | |
| Rated Load (kg) | 5000 | ||
| Opera ng Weight(kg) | ≈18500 | ||
| Max. Tractive Force (KN) | ≥150 | ||
| Breakout Force (KN) | ≥160 | ||
| Overall Dimensions(L×W×H) | 8700X3016X3380 | ||
| Dumping Height(mm) | 3100 / 3400 | ||
| Dumping Distance(mm) | 1100 / 1300 | ||
| Wheel base(mm) | 3260 | ||
| Wheel Tread(mm) | 2290 | ||
| Max. Turning Angle (°) | 35 | ||
| Max Gradeability (%) | 53% | ||
| Forward I (Km/h) | 12 | ||
| Forward ll (Km/h) | 32 | ||
| Backward (Km/n) | 24 | ||
| Battery Power System | Battery Type | Lithium iron phosphate | |
| Ambient Temperature(C) | -35~+60 | ||
| Thermal Management Mode | Heating film heating, water cooling | ||
| Rated Energy Capacity (kwh) | 282 | ||
| Rated Capacity(Ah) | 228 | ||
| Charging Time | Fast charging：2.0-2.5h / Slow charging：8-10h (Based on charger) | ||
Charging Method | Single gun independent charging/Dual guns charging together | ||
| Service Voltage Range(V) | 618 | ||
| Service Life (25℃，100%SOC) | 4000Cycles， Capacity fade ＜30% | ||
| Drive System | Travel Motor | ||
| Motor Type | Permanent magnet synchronization | ||
| Rated Power (kW) | 120 | ||
| Rated Voltage(V) | 380V | ||
| Transmission Type | hydraulic | ||
| Transmission Gear | 2 Forward 1 Reverse | ||
| Main Drive | Spiral bevel gear one stage reduction | ||
| Hub Reductor type | Spur gear planet drive | ||
| Tire | 23.5-25-16PR | ||
| Braking System | Hydraulic caliper disc brake | Hydraulic caliper disc brake | |
| Flexible shaft control drum brake | Hydraulic caliper disc brake | ||
| Steering Hydraulic System | Type | Full hydraulic on-load sensing steering system | |
| output volume (Steering Pump) | 80ml/r | ||
| Service Pressure (Mpa) | 15 | ||
| Steering Angle | ±35 | ||
| Service Hydraulic System | Hydraulic Pump Motor： | ||
| Permanent magnet synchronization | Permanent magnet synchronization | ||
| Rated Power (kW) | 90 | ||
| Rated Voltage(V) | 380V | ||
| Output volume (Variable piston pump + Internal gear pump) | 100+80ml/r | ||
| Working pressure (Mpa) | 18 | ||
| Total Cycle Time | Dump | Lowing(unload) | Total |
| 1.5s | 4.5s | 12.0s | |
| Electrical System | Battery Voltage (24V) | 24 | |
| Battery Capacity (Ah) | 60 | ||
| Lighting Voltage(V) | 24 | ||
| Oil Capacity | Hydraulic Oil (L) | 270 | |
| Transmission Oil (L) | 49 | ||
| Dive/Steering Oil (L) | 28 / 28 | ||
