25t SOCMA Logistic Port Heavy Duty Forklift
SOCMA HNF-250
Capacity:25t
Load center:1250mm
Lifting height:3.5 meters
Fujian SOCMA Machinery Manufacture Co., Ltd. is one of the leading manufacturers and suppliers of 25t socma logistic port heavy duty forklift in China. With a professional production team, we are able to meet the needs of the majority of our customers. Please rest assured to buy customized equipment at competitive price from our factory.
Model | Unit | HNF-250 | ||
Vehicle configuration | HNF-250 | |||
Performance | Rated load | kg | 25000 | |
Load center | mm | 1250 | ||
Mast tilt angle (front/rear) | º | 6/12 | ||
Overall dimensions | Length with fork | mm | 9190 | |
Width | mm | 3050 | ||
Height | mm | 3860 | ||
Mast lifting height | mm | 3500 | ||
Fork size (L*W*H) | mm | 2440X300X110 | ||
Min. turning radius | mm | 6700 | ||
Max. travel speed (with load) | Km/h | 24 | ||
Lifting speed (with load) | mm/s | 260 | ||
Gradeability (with load) | % | 20 | ||
Weight | Kg | 35000 | ||
Tyre | Front | 4X14.00-24/28PR | ||
Rear | 2X14.00- 24/28PR | |||
Wheel tread | Front | mm | 2200 | |
Rear | mm | 2390 | ||
Wheelbase | mm | 4400 | ||
Min. ground clearance | mm | 300 | ||
Engine | Model | CUNNINS QSC8.3-C240 | ||
Rated power/rotate speed | KW/r.pm | 179/2200 | ||
No. of cylinder | 6 | |||
