Product Introduction

SOCMA 15ton Electric Wheel Excavator for Construction with Lead Acid Battery

HNE150W-EL electric crawler excavator is a kind of earthwork construction equipment, which is suitable for mining, infrastructure, roads, hydropower, forestry, ports, freight yards, national defense and other projects. After the auxiliary device is configured, it can also carry out stone cleaning, disassembly, wood grabbing and steel grabbing, and has the functions of soil pushing and loading. It is a multi-purpose and high-efficiency construction machinery. The pure electric excavator has changed the traditional type of engine and diesel oil as the main power source, and adopted motor and lithium battery as the main power source, "zero emission, zero pollution, low noise and low energy consumption", so as to meet the national environmental requirements for energy conservation and emission reduction.

_20220527142738

_20220525150806

_20220527142807

_20220527142836

SPECIFICATION

Description			Unit	HNE150W-EL
Overall Size	Overall Length		mm	7645
	Overall Height		mm	3510
	Wheelbase		mm	2550
	Radius, Swing Center to Rear End		mm	2290
	Counterweight Ground Clearance		mm	1240
	Overall Width		mm	2500
	Tyre Distance		mm	1847
	Tyre Width		mm	586
	Min.Ground Clearance		mm	330
Working range parameter	Max. Digging Reach		mm	8175
	Max. Digging Depth		mm	5205
	Max. Digging Height		mm	9015
	Max. Dumping Height		mm	6380
	Max. Digging Reach on the Ground		mm	7985
Performance parameters	Whole Machine	Operating Weight	kg	13900
		Bucket Volume	m3	0.8
		Pressure to the Ground	KPa	45
		Travel SpeedLow/High	km/h	10/30
		Rotation Speed	rpm	12.4
		Gradeability	°	35
	Hydraulic System	Type		Negative flow system
		Work Pressure	MPa	28
		Flow	L/min	300
		Hydraulic Tank Capacity	L	170
	Working Device	Boom Length	mm	4600
		Arm Length	mm	3122
		Bucket Radius	mm	1328
	Digging Force	Max. Bucket Digging Force	kN	100
	Digging Force	Max. Arm Digging Force	kN	78
	Main Pump Electric Motor Parameters	Motor model		HP129D8-G202W-R8U4
		Motor Type		Permanent magnet synchronous motor
		Rated power	kW	92
		Rated torque	N	440
		Highest frequency	HZ	133.3
		Rated speed	r/min	2000
		Rated voltage	V	380
		Rated current	A	175
	Battery	Type		Lithium iron phosphate battery
		Storage power	kwh	210
		Rated voltage	v	608.6
		Rated capacity	Ah	346
		Type		Lithium iron phosphate battery
		Storage power	kwh	210
