Dimensions: 7640x2750x3625mm
Mast standard lifting height: 3500mm
Warranty time: one year or 2000 hours
Yuchai or DF Cummins engine
Dimensions: 7640x2750x3625mm
Mast standard lifting height: 3500mm
Warranty time: one year or 2000 hours
Luxurious cab configuration: air conditioning, reversing camera, fan, radio, etc.
Comes with configuration functions such as fork distance adjustment
| Configuration | Model | Unit | CPCD150 |
| Vehicle configuration | HNF-150 | ||
| Character | Rated Capacity | t | 15 |
| Load Center | mm | 900 | |
| Wheelbase | mm | 3800 | |
| Weight | Operation Weight | kg | 24000 |
| Chassis | Tyre, front | 12.00-24-18PR | |
| Tyre, rear | 12.00-20-18PR | ||
| Tyres Qty. front/rear (x=driving wheel) | 4×/2 | ||
| Wheel tread, front | mm | 2060 | |
| Wheel tread, rear | mm | 2330 | |
| Basic dimension | Mast Tilt Angle (front/rear) | ° | 6/12 |
| Mast height (fork lowered) | mm | 3625 | |
| Mast lifting height | mm | 3500 | |
| Max. lifting height | mm | 5375 | |
| Height to head guard (height to cab) | mm | 3365 | |
| Overall length (with fork) | mm | 7640 | |
| Fork front vertical surface to the rear end of the vehicle | mm | 5840 | |
| Overall width | mm | 2750 | |
| Fork dimension | mm | 1800x220x100 | |
| Fork carrier width | mm | 2700 | |
| Mast Min. ground clearance, full loaded | mm | 265 | |
| Wheelbase center Min. ground clearance | mm | 325 | |
| Min. turning radius | mm | 5800 | |
| Parameter | Travel speed (full loaded/without load) | km/h | 26/30 |
| Max. lifting speed (full loaded/without load) | mm/s | 250/260 | |
| Max. lowering speed (full load/without load) | mm/s | 430/330 | |
| Traction | kN | 150 | |
| Gradeability (full loaded/without load) | % | 20/22 | |
| Driving brake | Hydraulic clamp disc | ||
| Engine | Brand | DF Cummins | |
| QSB6.7-C190 EU III | |||
| Rated rotor speed | min-1 | 2200 | |
| No. of Cylinder | 6 | ||
| Transmission gears (Front/rear) | 2/1 | ||
| Attachments working pressure | Mpa | 16 | |
| Attachments using oil amount | L/min | 60 | |
